Tilting Indexing Device

Features

• For bigger quantity work, rapid indexing is simplified by use of replaceable notched rings can be notched to individual requirements.
• Rapid direct indexing through 360 degree by means of scales graduated in units of one degree division on the flanges.
• Indirect indexing is by means of worm and worm wheel giving direct reading of one minute on handwheel scales.
• The chuck can be swivelled up to 90°
• Worm Gear is easily and quickly detachable for direct indexing.
• Three Jaws chuck is standard equipment with one set of reverse jaws.
• The Graduation ring on hand knob is adjustable

Application

• An ideal indexing device for mechanics, tool makers and engravers for speedy and precision milling, drilling, boring and grinding operations.

Finish

• Blue Powder
